OVERVIEW
The Mitsubishi SVZ-KP18NA / SUZ-KA18NAHZ is a single-zone mini-split with an output of 18,000 BTU and an efficiency rating of 18.4 SEER. The slim design of the ceiling cassette makes it a perfect choice for any installation in which a wall mounted unit is impractical. With its Hyper Heat integrated technology, the SVZ-KP18NA / SUZ-KA18NAHZ is an excellent choice to heat and cool any room in your home all year.
QUICK FACTS
- Designed to be able to heat and cool up to a medium sized room (depending on climate)
- 18,000 BTU, 18.4 SEER single-zone mini-split
- Ceiling recessed to free up wall space in your room
- Slim design for easier installation
- Hyper Heat technology, allowing for functionality at down to -13°F
18,000 BTU, 18.4 SEER
With an output of 18,000 BTU, the Mitsubishi SVZ-KP18NA / SUZ-KA18NAHZ is suitable up to a medium sized room in an average climate. The unit also has a 18.4 SEER rating, making it able to efficiently heat and cool your home with ease. Please note that for all of these cassettes, a grille is required for proper installation and is available as an additional accessory.
Warranty
Mitsubishi provides a 5 year parts and 7 year compressor warranty from the factory. When the unit is installed following your state and local codes and is registered online through the manufacturer, the warranty is upgraded to a 10 year parts and compressor warranty.
The Mitsubishi SVZ-KP18NA / SUZ-KA18NAHZ is designed with intelligent controls that make small adjustments to keep the room’s temperature stable and bringing more comfort to your home. With an optional WiFi accessory, such as the Mitsubishi Kumo Cloud Adapter found here, this unit can be controlled from anywhere that you have Internet access—from across town at work to across the world on vacation—bringing ease of control to Mitsubishi’s superior comfort.
The Mitsubishi ceiling cassette on this unit is designed to fit between standard 16” joists and is only 7-1/2” deep. This low profile design allows the air handler to be installed in tighter spaces and eases the installation process. Designed to function down to -13°F, the SVZ-KP18NA / SUZ-KA18NAHZ is effective in even the coldest of winter months, making it extremely reliable.
Additional Information
| SKU | SVZ-KP18NA / SUZ-KA18NAHZ |
|---|---|
| Manufacturer | Mitsubishi |
| AHRI Certificate Number | 204627056 |
| Additional Information | Heat Pump |
| Additional Information | Maximum Line Set Length: 100' |
| Additional Information | Drain: 1-1/4" |
| HSPF | 10.4 |
| Cooling BTU | 18,000 BTU |
| Heating BTU | 21,600 BTU |
| Refrigerant | R410A |
| Refrigerant Charge | Pre-Charged For: 25' |
| Capacity | Dehumidification Rate: 0 gal/hr |
| SEER | 18 |
| EER | 12.5 |
| Condenser Stages | Variable Speed |
| Compressor Type | Rotary |
| Liquid Line | 1/4" |
| Suction Line | 1/2" |
| Electrical | 208/230V 1 Phase 60 Hz |
| Electric Phase Filter | Single Phase |
| Max Breaker Size | 31 |
| Min. Breaker Size | 17 |
| Tonnage | 1.5 Ton |
| System Tonnage | 1.5 Ton |
| Mini-Split Type | Unitary Ducted |
| Min/Max Outdoor Temp for Heating | -4°-75° |
| Min/Max Outdoor Temp for Cooling | 14°-115° |
| Low Ambient Heating | Yes |
| Zone Compatibility | Single Zone |
| Operating Mode | Cooling, Heating |
| Height | Indoor Unit: 39-13/16" | Outdoor Unit: 34-5/8 |
| Width | Indoor Unit: 17" | Outdoor Unit: 38-9/16 |
| Depth | Indoor Unit: 21-5/8" | Outdoor Unit: 13" |
| Weight (in lbs) | 162.0000 |
| Additional Info | Indoor Unit Weight: lbs | Outdoor Unit Weight: 131 lbs |
| Warranty | 10 Years with Online Registration |
| Resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
| Safety Information | PROPOSITION 65 WARNING |
