MRCOOL DIY 36,000 BTU 16 SEER Ductless Mini Split AC and Heat Pump with Wireless-Enabled Smart Controller
Model: DIY-36-HP-230B25

Regular Price: $2,811.25

Special Price $2,249.00

MRCOOL DIY 36,000 BTU 16 SEER Ductless Mini Split AC and Heat Pump with Wireless-Enabled Smart Controller

By: MRCOOL Model: DIY-36-HP-230B25 ID: 22045

Regular Price: $2,811.25

Special Price $2,249.00

Bread Checkout

FREE SHIPPING
Authorized MRCOOL Dealer
Ships in 2-3 Weeks
New

Regular Price: $2,811.25

Special Price $2,249.00

Accessories

Description

Details

Do you want a powerful and efficient heating and cooling system that is easy to install? Then the ideal product for you is the new MRCOOL 3rd gen DIY ductless mini-split heat pump with enhanced wifi. Designed to make setup quick and easy, the MRCOOL DIY is flexible enough to be installed virtually anywhere without requiring specialized tools or expensive equipment. The 36,000 BTU unit is 16 SEER and designed to efficiently heat and cool a single 1500 Sq. Ft. room. The new SmartHVAC app is compatible with Amazon Alexa and Google assistant. You can control your DIY anywhere with your Apple or android smart device and an Internet connection. When it comes to doing it yourself, the MRCOOL DIY is your best option. This unit is shipped in two boxes.

Features
  • New SmartHVAC app: wifi control - compatible with Amazon Alexa and Google assistant - you can control your DIY anywhere with your Apple or android smart device and an Internet connection
  • Easy DIY installation: pre-charged R-410A 25ft quick connect line doesn't require special tools, equipment, or training
  • Precharged 25' Quick Connect Line sets. These unique line sets are a cinch to get working. You’ll probably do it in less than 15 minutes.
  • Variable-speed DC inverter compressor technology cuts operating costs
  • Low ambient cooling: cooling down to 5°F - this feature makes the Mrcool DIY the ideal system for computer server rooms, greenhouses, and any other application that requires cooling all year
  • LEAKAGE DETECTION: Protecting Your Investment - When the MRCOOL DIY detects low coolant an alarm will sound to alert you to the problem. This will prevent damage to the compressor while you maintain high air comfort.
  • Auto restart: never lift a finger - power outage? don’t worry, the Mrcool DIY auto restart will have the unit running again in no time at all
  • Gold fin condenser: corrosion resistant - live on the coast? don’t worry, our condenser is built to resist long term corrosion
  • SLEEP mode on remote:Sleep mode will automatically adjust the temperature to maximize comfort during night time sleep. When in COOL mode, the unit will increase the temperature by 2°F after 1 hour, and will increase an additional 2°F after another hour. When in HEAT mode, the unit will decrease the temperature by 2°F after 1 hour, and will decrease an additional 2°F after another hour.After 7 hours operating in SLEEP mode, the system will switch off automatically.
  • 7-year compressor warranty and 5-year parts warranty
  • Follow me feature: by pressing the 'follow me' button and keeping the remote close to you, you tell the air conditioner to set the temperature from wherever the remote happens to be, this counteracts the tendency for the air conditioner to stop cooling or heating because the air around the unit has reached its set temperature
  • Auto mode feature: In the Auto mode,the mini split can logically choose the mode of Cooling,and Heating by sensing the difference between the actual ambient room temperature and the setting temperature on the remote control.
  • Dehumidifying operation:In DRY mode, the system will reduce the humidity of the air in the room for increased comfort.The air conditioner will automatically cycle between cooling and fan only modes to dehumidify the air.The temperature can be set within a range of 62F - 86F in 1 F increments.
  • LOUVER POSITION MEMORY: Remembers So You Don’t Have To - Horizontal louver will automatically move to the same position as you set last time the unit was turned on.
  • Four speed with oscillation operation.
  • Remote Included
Advantages
  • Two way draining connections further simplify installation and add flexibility.
  • Unlike any other ductless heat pump on the market, the MRCOOL DIY series mini-split system is specifically designed for easy, simple installation.
  • Most people can’t do their own electrical work, and that’s why the quick electrical connections on the MRCOOL DIY is a feature many will appreciate.
  • MRCOOL DIY temperature compensation technology helps keep you comfortable in any weather conditions.
  • Refrigerant leakage detection ensures your system remains operating efficiently without degradation due to undetected corrosion.
  • One of the most difficult aspects of typical heat pump installation is dealing with the refrigerant inside the coils. The MRCOOL DIY Series comes with precharged line sets avoiding one major obstacle to amateur installation in a single stroke.

Specifications

Additional Information

SKU DIY-36-HP-230B25
Manufacturer MRCOOL
Additional Information install this innovative ductless system easily
Additional Information The system constantly monitors interior air temperature
Additional Information Precharged 410 Quick Connect Line sets.
Additional Information Sleep Mode easy to program to save money
Additional Information Horizontal louver will automatically keep the last position
Cooling BTU 34,500 BTU
Heating BTU 36,000 BTU
Decibel Level (dBA) Indoor Unit: 35-52
Refrigerant R410A
Refrigerant Charge 119.9
SEER 16
EER 8.2
Liquid Line 3/8"
Suction Line 5/8"
Electrical 208/230V 1 Phase 60 Hz
Max Breaker Size 40 Amps
Min. Breaker Size 25 Amps
Tonnage 3 Ton
System Tonnage 3 Ton
Mini-Split Type Wall Mounted
Zone Compatibility Single Zone
Color White
Height Indoor Unit: 14.25" | Outdoor Unit: 31.89"
Width Indoor Unit: 49.57" | Outdoor Unit: 37.24"
Depth Indoor Unit: 11.10" | Outdoor Unit:16.14"
Weight (in lbs) 252.4300
Additional Info Indoor Unit Weight: 41.01 lbs | Outdoor Unit Weight: 150.35 lbs
Warranty 7 Years Compressor and 5 Years Parts Limited Warranty with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety Information PROPOSITION 65 WARNING

Reviews

Reviews

1 Customer review(s)
A professional looking MrCool 36K DIY install
First: HVACDirect.com website was easy to navigate to all the items I was in need of. Second: Shipping was fast and secure.
I have already installed the 3 ton MrCool 36K DIY, and the instructions were easy to follow. I do recommend getting the electrical installation kit for those that might not do electrical work on a regular basis. After installation the MrCool HVAC system looks professional, works great, and I know it will last for years. I plan to install more of these for the company I work for because of the quality, and ease of installation for the DIY consumer such as I am.
Quality
Price
Service
Review by Charlie / (Posted on 10/27/2020)

Write Your Own Review

You're reviewing: MRCOOL DIY 36,000 BTU 16 SEER Ductless Mini Split AC and Heat Pump with Wireless-Enabled Smart Controller

How do you rate this product? *


1 1 star
2 2 star
3 3 star
4 4 star
5 5 star
Quality
Price
Service

Product Q & A

Product Questions
Ask a Question Ask a Question

Sort By:



March 24, 2020Tommy J Lair asked:

Can I get a big unit to heat entire house? I have open living room dining room to kitchen and 3 bedrooms will


Answer
Single zone units are designed for 1 area. It will not spread to other rooms very well. -Thanks
