9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone GL - Air Handler
Model: MSZ-GL09NA
Low Price: $506.25

9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone GL - Air Handler

By: Mitsubishi Model: MSZ-GL09NA ID: 7088

More Views

Suggested Retail: $675.00
Low Price: $506.25
Today's Savings: $168.75
Bread Checkout
Authorized Mitsubishi Dealer
Ships in 4-6 Weeks
Low Price: $506.25
  • Low Price Guarantee
  • Award Winning Support




Please note that in order to function, this air handler must be installed with a condenser and other installation equipment, available at an additional cost.

  • Able to cover up to a small room in ideal conditions
  • 9,000 BTU wall-mounted air handler with remote
  • Automatic adjustments to match the thermostat’s needs
  • .225 gallon per hour dehumidification rate

The Mitsubishi MSZ-GL09NA air handler is designed to be able to function as a single zone system or with a multi zone system setup. This unit is manufactured as part of Mitsubishi’s standard air handler series, making it an inexpensive choice for efficient home comfort. With its ability to work with both cooling-only and heat pump condensers, the MSZ-GL09NA can function in almost any basic configuration and application. The unit also has the ability to ramp up and down based on the thermostat’s needs along with an automated vertical air swing adjustment system to direct the airflow where it needs to go, keeping you comfortable year-round with the right condenser.


Additional Information

Manufacturer Mitsubishi
Controller Wireless Included
Additional Information Drain: 5/8"
Cooling BTU 9,000 BTU
Heating BTU 10,900 BTU
Maximum CFM 109-406 CFM
Decibel Level (dBA) 19-43
Refrigerant R410A
Capacity Dehumidification Rate: 0.23 gal/hr
Liquid Line 1/4"
Suction Line 3/8"
Electrical 208/230v 1 Phase 60 Hz
Tonnage 0.75 Ton
Mini-Split Type Wall Mounted
Zone Compatibility Multi Zone
Operating Mode Cooling, Heating
Height 11-5/8"
Width 31-7/16"
Depth 9-1/8"
Weight (in lbs) 26.0000
Warranty 10 Years with Online Registration
Resources You will need Adobe® Acrobat® Reader to view PDF documents.
Safety Information PROPOSITION 65 WARNING



Be the first to review this product

Write Your Own Review

You're reviewing: 9,000 BTU Wall Mounted Mitsubishi Mini-Split Multi Zone GL - Air Handler

How do you rate this product? *

1 1 star
2 2 star
3 3 star
4 4 star
5 5 star

Product Q & A

Product Questions
Ask a Question Ask a Question

Sort By:


March 05, 2020Evan Langlois asked:

Does this model include the i-see 3D IR sensor?

No, you would want the MSZ-FH models if you are looking for the i-see 3D IR sensor -Thanks

February 11, 2020Anthony Patterson asked:


The condenser is not included, this is only the air handler - Thanks

May 26, 2018Steve cromer asked:

Is this a split unit only showing inside unit

This is just for the indoor unit. You would need to purchase the outdoor unit. Thanks!
