The new Daikin Sky Air system is built for absolute comfort and equipped with numerous comfort control features. Equipped with a new variable refrigerant temperature mode, this system will provide energy savings for most of the year while providing maximum comfort on extremely hot or cold days. The system is flexible, with a wide operating range and different mounts for the indoor unit to best suit your needs. Smart inverter technology reduces energy consumption by up to 30% or more and all products in the Sky Air system are designed to be highly efficient year round. The Sky Air system is also quiet, producing noise as low as 44 dB indoors and 59 dB outdoors. The system is designed to be installed where space is limited and the outdoor unit is compact and lightweight.
The Daikin Sky Air FTQ Series Multi-Positional Air Handler produces up to 16 SEER. It can be configured in a number of options and will operate at ambient temperatures down to -4 F.
Ductless mini-split systems are ideal for older buildings, in which running ductwork could cause damage and add expense to the installation process. They are also great for heating or cooling individual rooms or buildings that are detached from your main house or business.
Features- Heat Pump – This system provides heating and cooling.
- Configurable indoor unit – upflow/downflow, horizontal left or horizontal right
- 100% Heating capacity at -4F on systems up to 3 tons
Additional Information
| SKU | FTQ30TAVJUD / RZQ30TAVJU |
|---|---|
| Manufacturer | Daikin |
| AHRI Certificate Number | 202517170 |
| Additional Information | Heat Pump |
| Additional Information | Precharged for: 15' |
| Additional Information | Maximum Line Set Length: 230' |
| Additional Information | Drain: 1" |
| Additional Information | Indoor Unit Weight: 115 lbs | Outdoor Unit Weight: 225 lbs |
| HSPF | 10.4 |
| Cooling BTU | 30,000 |
| Heating BTU | 34,000 |
| Maximum CFM | 700-1000 CFM |
| Decibel Level (dBA) | Indoor Unit: 44-52 | Outdoor Unit: 57-59 |
| Refrigerant | R410A |
| SEER | 16 |
| EER | 12.5 |
| Compressor Type | Swing |
| Liquid Line | 3/8" |
| Suction Line | 5/8" |
| Electrical | 208/230V 1 Phase 60 Hz |
| Max Breaker Size | 35 Amps |
| Min. Breaker Size | 29.1 Amps |
| Tonnage | 2.5 Ton |
| System Tonnage | 2.5 Ton |
| Mini-Split Type | Unitary Ducted |
| Min/Max Outdoor Temp for Heating | -4°F - 60°F |
| Min/Max Outdoor Temp for Cooling | 23°F - 122°F |
| Low Ambient Heating | Yes |
| Zone Compatibility | Single Zone |
| Operating Mode | Cooling, Heating |
| Height | Indoor Unit: 45" | Outdoor Unit: 52-15/16" |
| Width | Indoor Unit: 17-1/2" | Outdoor Unit: 35-7/16" |
| Depth | Indoor Unit: 21" | Outdoor Unit: 12-5/8" |
| Weight (in lbs) | 340.0000 |
| Additional Info | Indoor Unit Weight: 115 lbs | Outdoor Unit Weight: 225 lbs |
| Commercial | Yes |
| Warranty | 10 Years with Online Registration |
| Resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
| Safety Information | PROPOSITION 65 WARNING |
