120,000 BTU 96% AFUE 2 Stage Goodman Gas Furnace - Upflow/Horizontal

OVERVIEW

As a high-efficiency system, the GMEC961205DN Goodman gas furnace features many money saving features. The two-stage, multi-speed furnace uses a superior heat exchanger for better heat transfers to your home. Considered one of the best efficiencies on the market, the GMEC961205DN is a good way to go if you want to lower your gas bill.

QUICK FACTS

• This furnace is ideal to heat a larger house (depending on climate)
• 120,000 BTU 96% AFUE natural gas furnace
• Requires plastic/PVC flue venting
• Can be used in the upflow or horizontal orientation
• Can be converted to an LP furnace with an optional conversion kit (sold separately)
• Innovative design for electrical efficiency, safety, and lower sound output

120,000 BTU

Heating up to a larger house in normal conditions, the GMEC961205DN Goodman gas furnace has an input of 120,000 BTU’s and an output of 115,200 BTU’s. The output in this case is determined by taking the input times the efficiency rating.

96% AFUE

The GMEC961205DN Goodman gas furnace is a 96% efficient furnace, making it a condensing setup. This efficiency means that only 4% of the fuel going into the furnace is used up in furnace operations, while 96% of the fuel is used to heat your home. As a condensing furnace, this furnace will need to be vented with plastic or PVC flue venting. If you need to use metal flue venting, you would need an 80% efficient furnace.

With a two stage burner, the GMEC961205DN provides two heating outputs: one at a 60% heating output and one at a 100% output. The furnace also has a multi speed ECM motor instead of the last-generation inefficient PSC motor. Both of these built-in upgrades allow for your furnace to adjust the heating output and airflow more precisely to better suit your home’s comfort needs and provide a slightly higher efficiency.

With installation that follows your state and local codes and with online registration, all Goodman furnaces come with a 10-year parts and lifetime heat exchanger warranty through the manufacturer.

The exterior casing on the GMEC961205DN is heavy-gauge steel that is insulated for enhanced protection and to lower air leakage and sound output from normal furnace operation. The hot surface ignitor is more efficient than earlier models and standing pilot lights thanks to its revolutionary new technology. Both of these end up saving you money on installation, maintenance, and bills.

The cost-saving benefits of the Goodman brand doesn’t stop at efficiency. The GMEC961205DN Goodman furnace can be upflow or horizontal, increasing the number of ways that your installer can install the system. The low-voltage terminals that are color-coded, the installation is faster and easier over standard non-colored systems. Straight from the factory, the GMEC961205DN comes with natural gas valves. However, increasing its versatility in installation, Goodman offers an LP conversion kit (found here at an additional cost) if you need it to be propane instead of natural gas. Not only does the Goodman brand save you money on installation costs, but also with maintenance and warranty work. In the event of a rare warranty issue, the on board self-diagnostic control board alerts you and your serviceman what is wrong with the unit for most basic issues for a faster solution.

3.5 Ton 14 SEER Goodman Heat Pump

OVERVIEW

The Goodman GSZ140421 heat pump condenser is a standard efficiency, low-cost solution for an all-electric home when paired with a suitable heat pump coil or air handler. Just like all of Goodman’s equipment, the GSZ140421 is manufactured with high-quality materials to provide a superior comfort in your home.

QUICK FACTS

• Ideal size to cover a medium-sized house in ideal climates
• 3.5 ton, 14 SEER heat pump condenser
• Low sound output
• Fully charged for up to 15’ of line set
• Factory-installed bi-flow filter drier

3.5 ton

The Goodman GSZ140421 heat pump has a capacity of 3.5 tons. In an ideal climate, this tonnage will normally cover up to a medium-sized house. In some bundles, the air handler or coil associated with this condenser may be intentionally larger in tonnage to maintain the unit’s overall efficiency. Please note that an indoor air handler or coil that is compatible with heat pumps is required for this unit to function.

14 SEER

At 14 SEER, the GSZ140421 heat pump condenser has the industry-standard minimum, allowing the unit to remain inexpensive upfront in comparison to higher SEER ratings. If you are replacing an existing heat pump, in most cases this SEER rating will still be higher than your old unit, allowing it to still save you money over time in energy bills.

The GSZ140421 condenser comes with Goodman’s standard 10 year parts warranty with online registration through the manufacturer. An installation that follows your state and local codes is required for the warranty to be upheld.

The Goodman GSZ140421 heat pump condenser is manufactured with a durable cabinet with paint that is approved for 500 hours of salt spray, making it compliant with the 2010 Florida building code unit integrity requirements for hurricane-like weather when properly anchored to your local codes. The built-in bi-flow liquids line filter drier protects the unit from impurities in the refrigerant and other general wear and tear, increasing the reliability of the unit.

The Goodman GSZ140421 has easily accessible gauge ports and service valves with sweat connections, allowing for a faster and easier installation process. There are factory-installed features such as a filter drier, compressor crankcase heater, pressure switches, and a high-capacity muffler so your installer doesn’t have to, further providing ease to the installation process. Moreover, the cabinet of the unit is fit with two maintenance access panels: one on the top and one on the side. All of these features lower your installation and maintenance costs, keeping more money in your pocket to spend on the things you care about most.

With its sound control top insulation and SmartShift technology for quiet and reliable defrost cycles, the GSZ140421 heat pump has some of the lowest sound outputs on a single stage unit on the market today.

4 to 5 Ton 24.5" Width Goodman Vertical Evaporator Cased Coil

The Goodman CAPF4860D6 Upflow/Downflow Cased Indoor Air Conditioner Evaporator Coil is made for use with split-system air conditioning and Evaporator systems. The Goodman Air Conditioning and Heating Company has become one of the largest manufacturers of residential and light commercial air conditioning, heating, and indoor air quality products and systems by focusing on just one thing, building the most reliable and refreshingly affordable indoor comfort products in the market.

• Suitable for use with R-410A and R-22 refrigerants
• Rust-resistant, thermoplastic drain pans feature a low water-retention design
• Check flowrater expansion device for heat pump or cooling-only applications
• Rifled aluminum tubing and louvered aluminum fin coils on the CAPF, CAUF, and CHPF coils
• AHRI Certified; ETL Listed
• Foil-face insulation
• Galvanized-steel, leather-grain finish
• Architectural Gray paint finish on CAPF and CHPF cased coils
• Split-seam front for easy access
• 17½”, 21”, and 24½” CAPF coils have two 1¾” adapter plates

Goodman 3.5 to 5 Ton TXV Kit - R-410A

Goodman's TXV valves are designed to improve the reliability and efficiency of your central split system. With the TX5N4, you can be assured that your three-and-a-half to five ton system is getting the proper refrigerant flow, even through changing conditions. Since this valve is installed externally, it is easy to service and maintain. If you're looking to improve the efficiency and performance of your system, the TX5N4 is a good start.

Product Compatible With

• Goodman GSX130421 Air Conditioners
• Goodman GSX130481 Air Conditioners
• Goodman GSX130601 Air Conditioners
• Goodman GSX130611 Air Conditioners
• Goodman DSXC160481 Air Conditioners
• Goodman DSXC160601 Air Conditioners
• Goodman DSXC160481 Air Conditioners
• Goodman DSXC160601 Air Conditioners
• Goodman GSZ130421 Heat Pumps
• Goodman GSZ130481 Heat Pumps
• Goodman GSZ130601 Heat Pumps
• Goodman SSZ140421 Heat Pumps
• Goodman SSZ140481 Heat Pumps
• Goodman SSZ140601 Heat Pumps
• Goodman SSZ160421 Heat Pumps
• Goodman SSZ160481 Heat Pumps
• Goodman SSZ160601 Heat Pumps
• Goodman DSZC160481 Heat Pumps
• Goodman DSZC160601 Heat Pumps
• Goodman DSZC180481 Heat Pumps
• Goodman DSZC180601 Heat Pumps
• Goodman CAPF3642*6 Evaporator Coils
• Goodman CAUF3642*6 Evaporator Coils
• Goodman CHPF3642B6 Evaporator Coils
• Goodman CSCF3642N6 Evaporator Coils
