An AirQuest combination system is a great choice to keep your home warm all season long. With tons of extra features and a great price, the G96CTN1202422A is a perfect choice for heating.
All AirQuest models are manufactured with Carrier and come with a 10 year parts warranty and 20 year heat exchanger limited warranty. Not intended for use in mobile homes.
120,000 BTU 96% AFUE Two-Stage Multi-Positional AirQuest Gas Furnace
The AirQuest G96CTN1202422A two-stage gas furnace is a great choice to keep your home warm all season long. With tons of extra features and a great price, the AirQuest G96CTN series is a perfect choice. All AirQuest models are manufactured with Carrier and come with a 10 year parts warranty and 20 year heat exchanger limited warranty. Not intended for use in mobile homes.
Furnace Features
- 96% AFUE
- Operates as a natural gas furnace out of the box, and can be easily converted to a propane furnace with optional propane conversion kit
- Direct vent (2-pipe), single-pipe venting or ventilated combustion air
- 24 VAC and 115 VAC humidifier terminal
- Electronic air cleaner terminal
- ESC blower motor
- Adjustable heating blower OFF delay
- Factory set blower ON delay
- RPJ aluminized steel heat exchanger
- Two-stage heating operation
- Variable speed, constant torque ECM blower motor
- Fully insulated steel cabinet for quieter operation
- Four position − upflow/downflow/horizontal (left/right) installation
- Through the casing flue pipe for counterflow applications
- Common venting with other Category I appliances
- Self diagnostics
- Slide out blower assembly
- 20 year heat exchanger limited warranty
- 5 year parts limited warranty - With timely registration, an additional 5 year parts limited warranty
3 Ton 16 SEER Two Stage AirQuest Heat Pump
OVERVIEW
With its communicating nature and its two stage compressor, the AirQuest HCH636GKA lives up to its Carrier manufacturer name, providing one of the most superior comforts to your home on the market today.
QUICK FACTS
- 3 ton, 16 SEER heat pump condenser
- Can heat and cool up to a medium-sized house in average conditions
- Two stage compressor with communicating capabilities with other matching system components
- Filter drier included to be field-installed and suction line accumulator factory-installed
- Built-in temperature sensor for automated heat source transition
- Multiple safety switches to protect both the unit and your home
- Energy Star certified
3 Tons
The AirQuest HCH636GKA heat pump condenser has an output of 3 tons, generally enough to heat and cool up to a medium-sized house in ideal climates. In many system configurations, the tonnage of the unit???s paired coil or air handler will be larger in tonnage than this condenser, which maintains the efficiency of the unit.Please note that this condenser cannot function on its own, and it needs an indoor coil or air handler to work. This unit will also only heat down to around 35??F, and if you need heat any lower than this, a backup heat strip will be needed to act as straight electric heating in a compatible air handler.
16 SEER
The AirQuest HCH636GKA air conditioner condenser is rated at 16 SEER, making it approximately 12% more efficient than the minimum efficiency 14 SEER units, saving you money in electric bills over the entire lifetime of your unit. In general, heat pumps will heat more efficiently than straight electric furnaces, making them an excellent and money-saving solution for almost any all-electric solution, especially when you have a lot of heating during outdoor temperatures ranging from when you start using your heating system all the way down to 35??F.
AirQuest offers a 10 year parts warranty on its condensers, and on this unit there is also a 10 year no hassle replacement limited warranty. For these warranties to be upheld, the unit must be installed following your state and local codes, a new and certified coil must be installed at the same time, and the entire system must be registered online through the manufacturer.
Engineered to be 2 stage and with the ability to communicate with communicating air handler counterparts, the AirQuest HCH636GKA can support a more precise temperature output, providing primarily enhanced comfort to your home year-round. Moreover, this unit is a communicating system when paired with a compatible air handler and other accessories (both available at an additional cost), allowing it to relay information to and from the thermostat constantly for optimal performance. On top of these benefits, these system features provide a small efficiency boost, all amounting to one of the best types of systems on the market today.
AirQuest 4 Ton 24.5" Width Vertical Evaporator Cased Coil
OVERVIEW
AirQuest takes pride in its ability to provide a high-quality system, including all system components. Leaving no exception, the END4X48L24A vertical coil is a superior option for almost any application while maintaining the entire unit???s efficiency with a factory-integrated TXV kit for enhanced energy optimization.
QUICK FACTS
- 4 ton vertical coil
- Works in both upflow and downflow applications
- Compatible with both AC-only and heat pump condensers
- Factory-installed TXV kit for enhanced energy optimization
- Sturdy and compact design
4 Tons
The AirQuest END4X48L24A is rated for up to 4 tons of heating and cooling. With its ability to be installed with either an AC-only condenser or a heat pump condenser, this unit is ideal for many applications. In some packages, this coil will be larger than its paired condenser, which will increase the overall efficiency of the entire unit, but the coil should never be smaller than its paired condenser. Please note that this item cannot operate independently from a compatible condenser and blower or furnace, each available at an additional cost.
Warranty
AirQuest offers a 10 year parts warranty on their coils when they are installed following your state and local codes, as well as the system is paired with a certified system matchup. Please note that in order to obtain the entire length of this warranty, the entire unit must be registered through the manufacturer.
Ion System Control
- High resolution, smartphone-like touchscreen
- Wi-Fi enabled for remote access and control
- Pair with our communicating, modulating gas furnace; variable-speed fan coil; inverter-driven outdoor units; and zoning system for a complete Ion Comfort System
- Capable of controlling temperatures and fan speeds in up to eight zones
- Local weather 5-day forecast
- Humidity control for enhanced comfort
- Dual fuel system management capable
- Auto changeover between heating and cooling
- Four levels of "constant ON" fan speeds
- 7-day programming with temperature control throughout the day and week (wake, away, home, sleep)
- Advanced smart setback for optimal energy savings during "away" and ramp up periods
- One-button Touch-N-Go quick-settings-change feature
- Simple vacation programming controls temperature and humidity
- System maintenance reminders
- 10-Year No Hassle Replacement Limited Warranty
120,000 BTU 96% AFUE Two-Stage Multi-Positional AirQuest Gas Furnace
sku | G96CTN1202422A |
---|---|
manufacturer | AirQuest |
carrier_equal | Carrier Equivelant: 59TN6B120C24--22 Tempstar Equivalent: F96CTN1202422A Bryant Equivelant: 986TC60120C24 |
afue | 96% |
heating_btu | 120,000 |
blower_motor | Variable Speed |
cfm | 2135 |
configuration | Upflow/Downflow/Horizontal |
exhaust_pipe | Plastic / PVC |
flue_requirement | Plastic / PVC |
energy_star | Yes |
electrical | 120 V. 1 Phase 60 Hz |
burner_stages | Two |
fuel_type | Gas |
height | 35" |
width | 24 1/2" |
depth | 29 1/2" |
weight | 195.0000 |
warranty | 10 Years No Hassle Replacement Warranty with Online Registration |
resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
safety_information |
This gas appliance requires a trained technician to install. Improperly connecting gas lines or improperly connecting a gas flue or venting may result in death. By purchasing this item, you are agreeing that you are using a trained technician to install this gas appliance. We will not be responsible for any injury or property damage arising from improper service or service procedures. Whoever installs or services this unit assumes responsibility for any personal injury or property damage which may result. Many jurisdictions require a license to install this equipment.
PROPOSITION 65 WARNING |
3 Ton 16 SEER Two Stage AirQuest Heat Pump
sku | HCH636GKA |
---|---|
manufacturer | AirQuest |
carrier_equal | Carrier Equivelant: 25HNB636A003 Tempstar Equivalent: TCH636GKA Bryant Equivelant: 286BNA036000 |
cooling_btu | 36,000 |
heating_btu | 36,000 |
energy_star | Yes |
refrigerant | R410A |
seer | 16 |
compressor_stage | Two Stage |
compressor_type | Scroll |
liquid_valve_size | 3/8" |
suction_valve_size | 7/8" |
electrical | 208 / 230 V. 1 Phase 60 Hz |
max_breaker_size | 35 amps |
min_breaker_size | 21.8 amps |
nominal_capacity | 3 Ton |
height | 43.5" |
width | 35" |
depth | 35" |
weight | 270.0000 |
warranty | 10 Years No Hassle Replacement Warranty with Online Registration |
resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
safety_information | PROPOSITION 65 WARNING |
AirQuest 4 Ton 24.5" Width Vertical Evaporator Cased Coil
sku | END4X48L24A |
---|---|
manufacturer | AirQuest |
carrier_equal | Carrier Equivelant: CNPVP4824ALA Tempstar Equivalent: END4X48L24A Bryant Equivelant: CNPVP4824ALA |
configuration | Upflow / Downflow |
liquid_line | 3/8" |
suction_line | 7/8" |
nominal_capacity | 4 Ton |
style | N-Coil |
height | 22 1/16" |
width | 24 1/2" |
depth | 21" |
weight | 62.0000 |
warranty | 10 Years with Online Registration |
resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
safety_information | PROPOSITION 65 WARNING |
Ion System Control
sku | SYST0101CW |
---|---|
manufacturer | AirQuest |
weight | 1.0000 |
resources | You will need Adobe® Acrobat® Reader to view PDF documents. |
safety_information | PROPOSITION 65 WARNING |
Reviews
- Fantastic customer support.
-
I'm using most of the features this controller offers and it was tricky to get my old ventilator working with this new HVAC system. When we exhausted the knowledge in-house at HVACdirect.com, they referred me to a local expert who stuck with me until all capabilities were functioning perfectly. One thing to know about this controller... If running a whole house ventilation system... there is a 1-1/2 minute delay before the furnace fan begins to do its part. That delay kept me wondering what was wrong for a few weeks but now it all works perfectly. Highly recommend HVACdirect.com and the ION system controller.
