An AirQuest combination system is a great choice to keep your home warm all season long. With tons of extra features and a great price, the G80CTL1352422A is a perfect choice for heating.
All AirQuest models are manufactured with Carrier and come with a 10 year parts warranty and 20 year heat exchanger limited warranty. Not intended for use in mobile homes.
135,000 BTU 80% AFUE Two Stage Multi-Positional AirQuest Gas Furnace
With its variable speed blower motor and two stage burner, the AirQuest G80CTL1352422A can provide a consistently superior comfort to almost any application.
- 135,000 BTU, 80% AFUE natural gas furnace
- Generally suitable for up to a large house in ideal applications
- Communicating variable speed blower with a two stage burner
- Multi-positional design—can be installed in the upflow, downflow, or horizontal orientations
- California Low NOx compliant
- Field-convertible to propane with an optional LP kit
- On board self-diagnostics
135,000 BTU, 80% AFUE
The AirQuest G80CTL1352422A has an input of 135,000 BTU. With an efficiency of 80%, this means that the furnace has an output of 108,000 BTU. The 80% AFUE also means that for the gas going into the furnace, 80% of it is used to heat your home while the remaining 20% is lost out the flue piping and lost to normal furnace operations. All 80% furnaces require metal flue venting, and if you need it to be plastic/PVC venting a furnace with an efficiency of 90% or above is required. While this unit uses natural gas as fuel out of the box, we also have an LP conversion kit, available at an additional cost.
AirQuest offers Carrier’s standard 10 year parts warranty and lifetime (20 year) heat exchanger limited warranty. Please note that in order for these warranties to be upheld, installation following your state and local codes are required, along with timely registration through the manufacturer.
Installation and Durability
With its ability to be installed in any configuration—upflow, downflow, or horizontal—the AirQuest G80CTL1352422A manufactured by Carrier is very versatile in application potential. The unit has a durable outer casing that can withstand wear-and-tear through its entire lifetime, providing the peace of mind that your home will stay comfortable year-round. Please note that this furnace is not designed to be suitable for a mobile home on its own.
All AirQuest-brand equipment is manufactured by Carrier, one of the leaders of superior comfort in the industry. The AIrQuest G80CTL1352422A definitely lives up to the Carrier family name thanks in part to its communicating variable speed blower motor and its two stage burner. Both of these prominent features provide the most precise temperature and airflow output possible, making you as comfortable as possible in your home year-round.
3 Ton 16 SEER Two Stage AirQuest Heat Pump
With its communicating nature and its two stage compressor, the AirQuest HCH636GKA lives up to its Carrier manufacturer name, providing one of the most superior comforts to your home on the market today.
- 3 ton, 16 SEER heat pump condenser
- Can heat and cool up to a medium-sized house in average conditions
- Two stage compressor with communicating capabilities with other matching system components
- Filter drier included to be field-installed and suction line accumulator factory-installed
- Built-in temperature sensor for automated heat source transition
- Multiple safety switches to protect both the unit and your home
- Energy Star certified
The AirQuest HCH636GKA heat pump condenser has an output of 3 tons, generally enough to heat and cool up to a medium-sized house in ideal climates. In many system configurations, the tonnage of the unit???s paired coil or air handler will be larger in tonnage than this condenser, which maintains the efficiency of the unit.Please note that this condenser cannot function on its own, and it needs an indoor coil or air handler to work. This unit will also only heat down to around 35??F, and if you need heat any lower than this, a backup heat strip will be needed to act as straight electric heating in a compatible air handler.
The AirQuest HCH636GKA air conditioner condenser is rated at 16 SEER, making it approximately 12% more efficient than the minimum efficiency 14 SEER units, saving you money in electric bills over the entire lifetime of your unit. In general, heat pumps will heat more efficiently than straight electric furnaces, making them an excellent and money-saving solution for almost any all-electric solution, especially when you have a lot of heating during outdoor temperatures ranging from when you start using your heating system all the way down to 35??F.
AirQuest offers a 10 year parts warranty on its condensers, and on this unit there is also a 10 year no hassle replacement limited warranty. For these warranties to be upheld, the unit must be installed following your state and local codes, a new and certified coil must be installed at the same time, and the entire system must be registered online through the manufacturer.
Intelligently Enhanced Comfort
Engineered to be 2 stage and with the ability to communicate with communicating air handler counterparts, the AirQuest HCH636GKA can support a more precise temperature output, providing primarily enhanced comfort to your home year-round. Moreover, this unit is a communicating system when paired with a compatible air handler and other accessories (both available at an additional cost), allowing it to relay information to and from the thermostat constantly for optimal performance. On top of these benefits, these system features provide a small efficiency boost, all amounting to one of the best types of systems on the market today.
AirQuest 3.5 Ton 24.5" Width Multi-Positional Evaporator Cased Coil
AirQuest takes pride in its ability to provide a high-quality system, including all system components. Leaving no exception, the EAM4X42L24A horizontal coil is a superior option for almost any application while maintaining the entire unit’s efficiency with a factory-integrated TXV kit for enhanced energy optimization. With its unique performance features along with its ability to be applied in any orientation, this coil is a superior option for your home’s comfort.
- 3.5 ton multi-positional evaporator coil
- Works in almost any application—whether you have an upflow, downflow, or horizontal system setup
- Compatible with both AC-only and heat pump condensers
- Factory-installed TXV kit for enhanced energy optimization
- Sturdy and compact design
The AirQuest by Carrier EAM4X42L24A is rated for up to 3.5 tons of heating and cooling. With its ability to be installed with either an AC-only condenser or a heat pump condenser, this unit is ideal for many applications. In some packages, this coil will be larger than its paired condenser, which will increase the overall efficiency of the entire unit, but the coil should never be smaller than its paired condenser. Please note that this item cannot operate independently from a compatible condenser and blower or furnace, each available at an additional cost.
AirQuest offers a 10 year parts warranty on their coils when they are installed following your state and local codes, as well as the system is paired with a certified system matchup. Please note that in order to obtain the entire length of this warranty, the entire unit must be registered through the manufacturer.
