120,000 BTU 96% AFUE Single Stage Goodman Gas Furnace - Upflow/Horizontal

OVERVIEW

The GMES961205DN Goodman gas furnace features high-quality construction and efficient operation at a great value. The GMES961205DN single-stage, multi-speed furnace utilizes Goodman's superior heat exchanger design to provide efficient, reliable heating to your home. If you're looking to cut your energy bills and improve your comfort without breaking the bank, your search stops with the Goodman GMES961205DN.

QUICK FACTS

• This furnace is ideal to heat a smaller house (depending on climate)
• 120,000 BTU 96% efficient natural gas furnace
• Requires plastic/PVC flue venting
• Can be used in the upflow or horizontal orientation
• Can be converted to an LP furnace with a conversion kit (sold separately)
• Innovative design for electrical efficiency, safety, and lower sound output

120,000 BTU

The GMES961205DN Goodman gas furnace is 120,000 BTU’s, which is the largest Goodman furnace size currently available. This BTU count is a measure of the input of the furnace per hour, while the output of this furnace is 115,200 BTU’s (120,000 X 96% AFUE) per hour. In ideal climate conditions, this 120,000 BTU furnace is usually used to heat a small house.

96% Efficiency Rating

The GMES961205DN Goodman gas furnace is 96% efficient, which is one of the highest efficiencies for gas furnaces on the market today. This efficiency means that 96% of the gas going into the furnace is used to heat your home, while the remaining 4% is lost to the furnace operation itself. Please note that all furnaces that are 90% efficient and above require plastic/pvc flue venting, while 80% efficient furnaces require plastic/PVC flue venting.

The GMES961205DN Goodman gas furnace is a single stage furnace has only one heat output. Regardless of the indoor temperature, this furnace will burn at 100% output whenever the thermostat calls for it. Like a light switch, this furnace’s burner will either be on or off and nothing in between. A single stage furnace is the standard efficient furnace since every time your furnace turns on the furnace uses the same amount of energy.

From the factory, the GMES961205DN runs on natural gas. However all Goodman gas furnaces can be converted to propane using the furnace’s corresponding LP conversion kit, an optional accessory at an additional cost that consists of a replacement set of orifices and springs.

Instead of the last generation PSC blower motor, the GMES961205DN utilizes a multi-speed ECM motor, which uses less power and provides smarter air circulation. All of this causes an overall increase in the electrical efficiency of your furnace, which saves you money.

With installation that follows your state and local codes and with online registration, all Goodman furnaces come with a 10-year parts and lifetime heat exchanger warranty through the manufacturer.

The hot surface igniter on modern Goodman furnaces are more durable than previous designs, decreasing related issues and lowering maintenance costs. These hot surface ignitors are also more efficient than standing pilot and older HSI designs, saving you even more money.

The Goodman brand has improved technology from years of production experience, allowing for a long-lasting product that rarely has any issues. However, if something does go wrong on the furnace, the control board has a set of sensors that allow it to diagnose basic issues, allowing for easy troubleshooting and to notify the owner if basic maintenance or warranty work is recommended. This increases the overall safety of the unit, for the furnace itself and the occupants of the home where it is installed.

The heavy-gauge steel cabinet on new Goodman furnaces provide adequate protection to the internal mechanisms of the unit. The cabinet is also more air-tight than previous models, allowing for a quiet, more economical unit due to losing less heat and preventing more sound from exiting the unit.

The value of modern Goodman furnaces doesn't end at efficiency. Today’s Goodman furnaces feature many different connection options to reduce installation. The GMES961205DN model has a more universal design, which consists of its ability to be installed in both an upflow or horizontal configuration. This allows for an easier installation in more locations, from your attic to your basement. The furnace also comes with color-coded low-voltage terminals that allow for a shorter and easier installation time, which decreases installation costs.

3.5 Ton 14 SEER Goodman Heat Pump

OVERVIEW

The Goodman GSZ140421 heat pump condenser is a standard efficiency, low-cost solution for an all-electric home when paired with a suitable heat pump coil or air handler. Just like all of Goodman’s equipment, the GSZ140421 is manufactured with high-quality materials to provide a superior comfort in your home.

QUICK FACTS

• Ideal size to cover a medium-sized house in ideal climates
• 3.5 ton, 14 SEER heat pump condenser
• Low sound output
• Fully charged for up to 15’ of line set
• Factory-installed bi-flow filter drier

3.5 ton

The Goodman GSZ140421 heat pump has a capacity of 3.5 tons. In an ideal climate, this tonnage will normally cover up to a medium-sized house. In some bundles, the air handler or coil associated with this condenser may be intentionally larger in tonnage to maintain the unit’s overall efficiency. Please note that an indoor air handler or coil that is compatible with heat pumps is required for this unit to function.

14 SEER

At 14 SEER, the GSZ140421 heat pump condenser has the industry-standard minimum, allowing the unit to remain inexpensive upfront in comparison to higher SEER ratings. If you are replacing an existing heat pump, in most cases this SEER rating will still be higher than your old unit, allowing it to still save you money over time in energy bills.

The GSZ140421 condenser comes with Goodman’s standard 10 year parts warranty with online registration through the manufacturer. An installation that follows your state and local codes is required for the warranty to be upheld.

The Goodman GSZ140421 heat pump condenser is manufactured with a durable cabinet with paint that is approved for 500 hours of salt spray, making it compliant with the 2010 Florida building code unit integrity requirements for hurricane-like weather when properly anchored to your local codes. The built-in bi-flow liquids line filter drier protects the unit from impurities in the refrigerant and other general wear and tear, increasing the reliability of the unit.

The Goodman GSZ140421 has easily accessible gauge ports and service valves with sweat connections, allowing for a faster and easier installation process. There are factory-installed features such as a filter drier, compressor crankcase heater, pressure switches, and a high-capacity muffler so your installer doesn’t have to, further providing ease to the installation process. Moreover, the cabinet of the unit is fit with two maintenance access panels: one on the top and one on the side. All of these features lower your installation and maintenance costs, keeping more money in your pocket to spend on the things you care about most.

With its sound control top insulation and SmartShift technology for quiet and reliable defrost cycles, the GSZ140421 heat pump has some of the lowest sound outputs on a single stage unit on the market today.

4 to 5 Ton 24.5" Goodman Horizontal Evaporator Cased Coil

OVERVIEW

The Goodman CHPF4860D6 evaporator coil is designed for any installations that the coil needs to sit on its side, in the horizontal position. With its enhanced comfort and superior efficiency design, the CHPF4860D6 is an inexpensive yet quality choice for you.

QUICK FACTS

• 4 to 5 ton evaporator coil
• Installable in the horizontal configuration
• Usable with either a heat pump or an AC-only condenser
• Works with R410A or R22 refrigerant
• Low air leakage
• Check flowrater expansion device for use in any application

4 to 5 Tons

At an output of 4 to 5 tons, the Goodman CHPF4860D6 evaporator coil is ready for almost any horizontal installation at that size. In many situations, a condenser that is paired with the condenser is going to be smaller than this coil. This is intentional and is to maintain the overall unit’s efficiency.
Please note that for this coil to function, a furnace or blower and a condenser is required, all sold separately. This coil is not designed to replace a coil in a single-piece air handler.

Warranty

The CHPF4860D6 coil is covered under Goodman’s standard 10 year parts warranty when the unit is installed following your state and local codes, the coil is paired with a compatible R410A condenser, and the entire system is registered online through the manufacturer.

The Goodman CHPF4860D6 evaporator coil is designed with a durable outer casing and a rust-resistant drain pan to lower general wear and tear to make sure the coil works for years to come. To ease installation, the unit is designed to be slim and able to fit in many crawl spaces and attics, and with its foil-face insulation making the unit’s air leakage minimal, installation location does not necessarily have to be insulated for normal temperature operations. For maintenance, the coil has a split-seam on the front of it for easier access.

Goodman 3.5 to 5 Ton TXV Kit - R-410A

Goodman's TXV valves are designed to improve the reliability and efficiency of your central split system. With the TX5N4, you can be assured that your three-and-a-half to five ton system is getting the proper refrigerant flow, even through changing conditions. Since this valve is installed externally, it is easy to service and maintain. If you're looking to improve the efficiency and performance of your system, the TX5N4 is a good start.

Product Compatible With

• Goodman GSX130421 Air Conditioners
• Goodman GSX130481 Air Conditioners
• Goodman GSX130601 Air Conditioners
• Goodman GSX130611 Air Conditioners
• Goodman DSXC160481 Air Conditioners
• Goodman DSXC160601 Air Conditioners
• Goodman DSXC160481 Air Conditioners
• Goodman DSXC160601 Air Conditioners
• Goodman GSZ130421 Heat Pumps
• Goodman GSZ130481 Heat Pumps
• Goodman GSZ130601 Heat Pumps
• Goodman SSZ140421 Heat Pumps
• Goodman SSZ140481 Heat Pumps
• Goodman SSZ140601 Heat Pumps
• Goodman SSZ160421 Heat Pumps
• Goodman SSZ160481 Heat Pumps
• Goodman SSZ160601 Heat Pumps
• Goodman DSZC160481 Heat Pumps
• Goodman DSZC160601 Heat Pumps
• Goodman DSZC180481 Heat Pumps
• Goodman DSZC180601 Heat Pumps
• Goodman CAPF3642*6 Evaporator Coils
• Goodman CAUF3642*6 Evaporator Coils
• Goodman CHPF3642B6 Evaporator Coils
• Goodman CSCF3642N6 Evaporator Coils
